Automatic Spring roll sheet making machine is mainly used for making Spring roll sheets, lumpia wrappers, samosa sheets, thin crepe or pancakes, and Chinese roast duck cakes.
Processing steps:
Batter paste mixing – batter filter – batter printing to the baking drum – sheets baking – cooling conveyor – counting and folding part – finished product conveyor belt – packing machine.
Finished Product:
Application:
Widely used in chain stores, central kitchens, food factories, restaurants, fast food restaurants, and other units.
Feature:
- Advanced temperature control system that accurately displays and controls the temperature.
- It boasts a high heat utilization rate with minimal heat loss, fulfilling the goals of energy conservation and environmental protection.
- The machine has a low production cost and a simple operating system, allowing it to be operated by a single person, thereby saving on labor.
- Temperature and thickness can be adjusted.
Parameter data:
| Model | AJ-3620 | AJ-5029 | AJ-8045 | AJ-12060 |
| Voltage | 380/220V（50/60HZ） | |||
| Dia. of heating Cylinder | 400mm | 500mm | 800mm | 1200mm |
| Power | 8/10kw or gas | 18kw or gas | 40kw or gas | 59kw or gas |
| Capacity | 500-1000pcs/h | 1000-1500pcs/h | 3500pcs/h | 9000pcs/h |
| Dimension | 4100*950*1350mm | 5200*950*1350mm | 6200*1100*1600mm | 6500*1300*2300mm |
| Rotating speed | 1-2.5r/min | 1-2.5r/min | 1-3r/min | 1-3r/min |
| Weight | 330kg | 520kg | 1000kg | 1750kg |
| Size of the Sheet ( Max.) | 200mm | 300mm | 450mm | 600mm |
| Thickness of the Sheet | 0.5-2.0mm | |||
| Note | Capacity based on spring roll sheet size, | |||
| the actual capacity is subject to the quotation list. | ||||
FAQ : About spring roll sheet making machine
Q1: The machine can use what kind of flour to make the batter paste?
A: This machine is most suitable for work with wheat flour.
Q2: How does the machine work?
A: The machine typically mixes flour and water to create a batter. After preparing the batter, the machine proceeds to spread it uniformly onto a heated surface, where it cooks to perfection and takes shape as the wrapper. After cooking, the machine automatically removes the wrapper from the surface.
Q3: What is the production capacity of the machine?
A: Production capacity varies based on the machine’s size and design. Capacities can range from a few hundred to thousands of wrappers per hour.
Q4: I’m a new beginner to spring roll wrapper making, what model I should choose?
A: Please provide your product specifications and hourly output. We will create a flow diagram and our engineer will design a custom factory based on your location.
