Automatic Sauce sachet packing machine for BBQ,Chili & Tomato Ketchup Sachet
Application:
Sauce sachet packing machine It is suitable for the metering and packaging of liquids, pastes, and sauces in the food, medicine, chemical, and cosmetics industries.
Features:
1. Sauce sachet packing machine is suitable for the metering and packaging of liquids and sauces in the food, medicine, chemical and cosmetics industries.
2. All the work of bag forming, measuring, filling, sealing, cutting, date printing, and counting is automatically. At the same time, we can also customize the batch number and other functions according to customers’ demands.
3. The touch screen operation, PLC control, drive stepper motor to control the bag length, stable performance, easy to adjust, and accurate detection. Choose the intelligent temperature controller and PID control to ensure the error range of temperature is controlled within 1 degree Centigrade.
4. Packing material: BOPP/Polyethylene, Aluminium/Polyethylene, Paper/Polyethylene
Parameter Data:
| Model | AJ -61JL |
| Packing material | Polypropylene/Polyethylene, Aluminum Foil/Polyethylene, Polyester/Aluminized/Polyethylene, Nylon/Reinforced Polyethylene, Paper/Polyethylene, etc. |
| Sealing Type | Three-side sealing/four-side sealing/back sealing |
| Measuring Scope | 1 – 100 g（3 – 100 ml） |
| Bag length | 30 – 170 mm |
| Bag width | 30 – 130 mm |
| Packing Speed | 30 – 60 bags/min |
| Dimension ( L * W * H ) | 900 * 1100 * 1590 mm |
| Weight | 400 kg |
| Total Power | 220V / 50Hz / 1.4kw |
Video for reference:
